AKT2G-SM-L50-000

Stepper motorClosed An actuator focused to a movement, converting electrical energy in a force or torque. terminal, 50 V DC, 5 A, vector control

The AKT2G-SM-L50 EtherCATClosed Ethernet ofr Control Automation Technology. EtherCAT® is an open, high-performance Ethernet-based fieldbus system. The development goal of EtherCAT is to apply Ethernet to automation applications which require short data update times (also called cycle times) with low communication jitter (for synchronization purposes) and low hardware costs. Terminal is intended for stepper motors with medium performance range. The PWM output stages cover a wide range of voltages and currents. Together with two inputs for limit switchesClosed Switch limiting the traverse path of the machine. Implemented as n.c. (break) contact. A sensor, typically Hall-effect, optical, eddy current, or mechanical, which is used to sense the end of travel of a linear motion assembly. In addition to preventing over travel, it is frequently used to establish a precision reference., they are located in the EtherCAT Terminal.

The SM-L50 can be adjusted to the motor and the application by changing just a few parameters. 64-fold micro-stepping ensures particularly quiet and precise motor operation. Together with a stepper motor and an encoderClosed Generates an output signal directly proportional to the movement of the motor shaft. This signal is fed into the control circuitry to control the shaft position and speed. The most common types are: Incremental/Serial encoders, Hall effect sensors, Resolvers, Tachometer Generators See: Optical encoders., the SM-L50 represents an inexpensive small servo axis.

The LEDs indicate status, warning and error messages as well as possibly active limitations.

Quick Links

Technical Data

Technical Data AKT2G-SM-L50
Number of outputs 1 stepper motor, 2 phases
Number of digital inputs 2 limit positionClosed Position means a point in space which is described by different coordinates. Depending on the used system and transformation it can consist of a maximum of six dimensions (coordinates).This means three Cartesian coordinates in space and coordinates for the orientation. In ACS there can be even more than six coordinates. If the same position is described in different coordinate systems the values of the coordinates are different., 4 for an encoder system
Number of digital outputs 1 configurable for brake (0.5 A)
Supply voltage 8 … 50 V DC
Motor Current/Phase (RMS) values without fan cartridge ZB8610 3.53 A
Motor Current/Phase (RMS) values with fan cartridge ZB8610 4.59 A
Maximum output current without fan cartridge AKT2G-AC-FAN-001 5 A (overload- and short-circuit-proof)
Maximum output current with fan cartridge AKT2G-AC-FAN-001 6.5 A (overload- and short-circuit-proof)
Operating modes
Maximum step frequency 1000, 2000, 4000, 8000 or 16000 full steps/s (configurable)
Step pattern up to 64-fold micro stepping (automatic switching, speed-dependent)
Current controllerClosed Regulates the difference between the current setpoint and the actual value to 0. Output : power output voltage. frequency approx. 30 kHz
Encoder pulseClosed When the step gets activated, the action is activated for a single execution, and possibly once again when the step is deactivated. frequency maximum 400,000 increments per second (4-fold evaluation)
Input signal voltage "0" -3 V … 2 V
Input signal voltage "1" 3.7 V … 28 V
Input Current typ. 5 mA
Diagnostics LED Warning strand A and B, error strand A and B, power, enableClosed Enable signal for the drive, Hardware-Enable with 24V signal to X8, Software-Enable command by setup Software, fieldbus or permanently set. Both are required for enabling the drive.
ResolutionClosed The resolution is the smallest possible movement that can be achieved by a system. It can be defined at the electronics, encoder and mechanics level. The distance a stage can be commanded to move in a single step. For servo systems, the basic increment produced by its optical encoder, or any other feedback device. approx. 5,000 positions in typical applications (per revolution)
Power Supply via the E-bus, encoder/driverClosed In computing and electronics, a driver is a software component allowing higher-level computer programs to interact with a computer hardware device. A driver typically communicates with the device through the computer bus or communications subsystem to which the hardware is connected. stage: via the power contacts, motor: via terminal contacts
Current consumption from the E-bus typ. 140 mA
Electrical isolation 500 V (E-bus/signal voltage)
Support NoCoEStorage yes
Configuration no address setting required
Weight approx. 105 g
Permissible ambient temperature range during operation 0°C ... +55 °C
Permissible ambient temperature range during storage -25°C ... + 85 °C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 27 mm x 100 mm x 70 mm (connected width: 24 mm)
Installation on 35 mm mounting rail according to EN 60715
Vibration / shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission according to EN 61000-6-2 / EN 61000-6-4
according to IECClosed International Electrotechnical Commission - A not-for-profit, non-governmental international standards organization that prepares and publishes International Standards for all electrical, electronic and related technologies./EN 61800-3
EMC category Category C3 - standard
Category C2, C1 - auxiliary filter required
Protection class IP 20
Installation position
  • without fan cartridge ZB8610: standard installing position
  • with fan cartridge ZB8610: standard installing position, other installing positions (example 1 & 2)
Approval CE cULus
