EtherCAT Communication Diagnosis Steps

This sample code checks for any Working Counter failure using the function ECATWCStatus. If there is one or more working counter errors then the return value will be greater than 0.

WC_ErrorCount := ECATWCStatus( 0 );
IF WC_ErrorCount > 0 THEN
   WC_error :=TRUE; // There is a communication problem.
   ELSE
   WC_error := FALSE; // No communication problem
END_IF;

The GetCtrlErrors function can be used to get the Errors and Alarms in the controller that are related to EtherCAT.

ControllerErrorStatus:= GetCtrlErrors(ActiveError, ActiveAlarm) ;
A31Active := ActiveAlarm[31]; // True if A31 is active.
   A38Active := ActiveAlarm[38]; // True if A38 alarm is active
   E30Active := ActiveError[30] // True if E30 is active.
   // Process the alarms and Errors here.

The device (slave) state can be read by the application using the function block ECATDeviceStatus.

Inst_ECATDeviceStatus(True, slaveAddress);
IF Inst_ECATDeviceStatus.Done THEN
   IF Inst_ECATDeviceStatus.LinkStatus = EC_LINK_NO_COMMUNICATION THEN
      device_not_reachable := TRUE; // Device is not reachable. Link to the device is broken.
   END_IF
   IF Inst_ECATDeviceStatus.State <> EC_STATE_OP THEN
      device_not_in_OPMODE := TRUE; // Slave is not in Operational mode.
   END_IF
END_IF;

This sample code uses ECATCommErrors function block to identify the connections that have errors.

Inst_ECATCommErrors( TRUE, connections);
IF Inst_ECATCommErrors.Done THEN
   IF  Inst_ECATCommErrors.ConnectionCount > 0 THEN
// Process the connection errors here.
   END_IF;
END_IF
